Brass

BRAWEA22080

Spec. Sheet

PDF

Centres or Mesh Count

1/2" x 1/2" (12.7 mm x 12.7 mm) c to c

Wire Diameter

0.080" (2.03 mm)

Clear Opening

0.420" (10.668 mm)

Percent Open Area

70.6%

Weight

0.917 lbs/sf (0.416 kgs/sf)
shop now

BRAWEA44047IC

Spec. Sheet

PDF

Centres or Mesh Count

4 x 4 MESH (6.4 mm x 6.4 mm) c to c

Wire Diameter

0.047" (1.19 mm)

Clear Opening

0.203" (5.156 mm)

Percent Open Area

65.90%

Weight

0.637 lbs/sf (0.289 kgs/sf)
shop now

BRAWEA66035

Spec. Sheet

PDF

Centres or Mesh Count

6 x 6 MESH (4.2 mm x 4.2 mm) c to c

Wire Diameter

0.035" (0.89 mm)

Clear Opening

0.132" (3.353 mm)

Percent Open Area

62.70%

Weight

0.532 lbs/sf (0.241 kgs/sf)
shop now

BRAWEA88028

Spec. Sheet

PDF

Centres or Mesh Count

8 x 8 MESH (3.2 mm x 3.2 mm) c to c

Wire Diameter

0.028" (0.71 mm)

Clear Opening

0.097" (2.464 mm)

Percent Open Area

60.20%

Weight

0.454 lbs/sf (0.206 kgs/sf)
shop now

BRAWEA1212023

Spec. Sheet

PDF

Centres or Mesh Count

12 x 12 MESH (2.1 mm x 2.1 mm) c to c

Wire Diameter

0.023" (0.58 mm)

Clear Opening

0.060" (1.524 mm)

Percent Open Area

51.80%

Weight

0.466 lbs/sf (0.212 kgs/sf)
shop now

BRAWEA1414020

Spec. Sheet

PDF

Centres or Mesh Count

14 x 14 MESH (1.8 mm x 1.8 mm) c to c

Wire Diameter

0.020" (0.51 mm)

Clear Opening

0.051" (1.295 mm)

Percent Open Area

51.00%

Weight

0.411 lbs/sf (0.186 kgs/sf)
shop now

BRAWEA2020016

Spec. Sheet

PDF

Centres or Mesh Count

20 x 20 MESH

Wire Diameter

0.016" (0.41 mm)

Clear Opening

0.034" (0.864 mm)

Percent Open Area

46.20%

Weight

0.380 lbs/sf (0.172 kgs/sf)
shop now

BRAWEA2424014

Spec. Sheet

PDF

Centres or Mesh Count

24 x 24 MESH

Wire Diameter

0.014" (0.36 mm)

Clear Opening

0.028" (0.711 mm)

Percent Open Area

44.20%

Weight

0.351 lbs/sf (0.159 kgs/sf)
shop now
Loading...

Ferrier Wire stocks and weaves a range of brass weavmesh for use in industrial filtration applications as well as architectural and design applications.
