Stainless Steel
Product Code : SSWEA1010020
Spec. Sheet
Centres or Mesh Count
10 x 10 MESH (2.5 mm x 2.5 mm) c to cWire Diameter
0.020" (0.508 mm)Clear Opening
0.080" (2.032 mm)Percent Open Area
64.00%Weight
0.264 lbs/sf (0.120 kgs/sf)
Product Code : SSWEA1010025
Spec. Sheet
Centres or Mesh Count
10 x 10 MESH (2.5 mm x 2.5 mm) c to cWire Diameter
0.025" (0.635 mm)Clear Opening
0.075" (1.905 mm)Percent Open Area
56.30%Weight
0.416 lbs/sf (0.189 kgs/sf)
Product Code : SSWEA1010035
Spec. Sheet
Centres or Mesh Count
10 x 10 MESH (2.5 mm x 2.5 mm) c to cWire Diameter
0.035" (0.889 mm)Clear Opening
0.065" (1.651 mm)Percent Open Area
42.30%Weight
0.839 lbs/sf (0.381 kgs/sf)
Product Code : SSWEA1010047
Spec. Sheet
Centres or Mesh Count
10 x 10 MESH (2.5 mm x 2.5 mm) c to cWire Diameter
0.047" (1.194 mm)Clear Opening
0.053" (1.346 mm)Percent Open Area
28.10%Weight
1.499 lbs/sf (0.680 kgs/sf)
Product Code : SSWEA1212028
Spec. Sheet
Centres or Mesh Count
12 x 12 MESH (2.1 mm x 2.1 mm) c to cWire Diameter
0.028" (0.711 mm)Clear Opening
0.055" (1.397 mm)Percent Open Area
43.60%Weight
0.641 lbs/sf (0.291 kgs/sf)
Product Code : SSWEA1212023
Spec. Sheet
Centres or Mesh Count
12 x 12 MESH (2.1 mm x 2.1 mm) c to cWire Diameter
0.023" (0.584 mm)Clear Opening
0.060" (1.524 mm)Percent Open Area
51.80%Weight
0.426 lbs/sf (0.193 kgs/sf)
Product Code : SSWEA1414020
Spec. Sheet
Centres or Mesh Count
14 x 14 MESH (1.8 mm x 1.8 mm) c to cWire Diameter
0.020" (0.508 mm)Clear Opening
0.051" (1.295 mm)Percent Open Area
51.00%Weight
0.376 lbs/sf (0.171 kgs/sf)
Product Code : SSWEA1616028
Spec. Sheet
Centres or Mesh Count
16 x 16 MESHWire Diameter
0.028" (0.711 mm)Clear Opening
0.035" (0.889 mm)Percent Open Area
30.50%Weight
0.844 lbs/sf (0.383 kgs/sf)
Industrial wire mesh and wire cloth for use in filtration and sifting applications with various 304 and 316 options. 304 stainless steel is food grade stainless steel and is also commonly referred to as 18/10 stainless steel. 316 grade stainless steel is a highly corrosion resistant option that is suitable for marine environments, making it a slightly more expensive option.
