Stainless Steel Weavemesh
Our stainless steel products lend themselves to a multitude of applications including filtering, wildlife control, railings, and concrete mesh. Our online catalog of stainless steel products includes both woven and welded wire mesh varieties that range from extremely rigid concrete reinforcement mesh to very fine mesh with thin gauge wire used for filtering and straining. Ferrier Wire mainly deals with 304 and 316 grade stainless steel. 304 stainless steel (also called 18/10 steel) is a food grade type of stainless steel that consists of 18% chromium and 10% nickel. 316 grade stainless steel is highly corrosion resistant and can be used in marine environments which may make it a slightly more expensive option. These stainless steel products can be plated or powder coated for an additional charge. For more information on powder coating and plating options, feel free to call or email us.
SSWEA1010025
Spec. Sheet
---Centres or Mesh Count
10 x 10 MESH (2.5 mm x 2.5 mm) c to cWire Diameter
0.025" (0.635 mm)Clear Opening
0.075" (1.905 mm)Percent Open Area
56.30%Weight
0.416 lbs/sf (0.189 kgs/sf)
SSWEA1010035
Spec. Sheet
---Centres or Mesh Count
10 x 10 MESH (2.5 mm x 2.5 mm) c to cWire Diameter
0.035" (0.889 mm)Clear Opening
0.065" (1.651 mm)Percent Open Area
42.30%Weight
0.839 lbs/sf (0.381 kgs/sf)
SSWEA1010047
Spec. Sheet
---Centres or Mesh Count
10 x 10 MESH (2.5 mm x 2.5 mm) c to cWire Diameter
0.047" (1.194 mm)Clear Opening
0.053" (1.346 mm)Percent Open Area
28.10%Weight
1.499 lbs/sf (0.680 kgs/sf)
SSWEA1212028
Spec. Sheet
---Centres or Mesh Count
12 x 12 MESH (2.1 mm x 2.1 mm) c to cWire Diameter
0.028" (0.711 mm)Clear Opening
0.055" (1.397 mm)Percent Open Area
43.60%Weight
0.641 lbs/sf (0.291 kgs/sf)
SSWEA1212023
Spec. Sheet
---Centres or Mesh Count
12 x 12 MESH (2.1 mm x 2.1 mm) c to cWire Diameter
0.023" (0.584 mm)Clear Opening
0.060" (1.524 mm)Percent Open Area
51.80%Weight
0.426 lbs/sf (0.193 kgs/sf)
SSWEA1414020
Spec. Sheet
---Centres or Mesh Count
14 x 14 MESH (1.8 mm x 1.8 mm) c to cWire Diameter
0.020" (0.508 mm)Clear Opening
0.051" (1.295 mm)Percent Open Area
51.00%Weight
0.376 lbs/sf (0.171 kgs/sf)
SSWEA1616028
Spec. Sheet
---Centres or Mesh Count
16 x 16 MESHWire Diameter
0.028" (0.711 mm)Clear Opening
0.035" (0.889 mm)Percent Open Area
30.50%Weight
0.844 lbs/sf (0.383 kgs/sf)
SSWEA1616018
Spec. Sheet
---Centres or Mesh Count
16 x 16 MESHWire Diameter
0.018" (0.457 mm)Clear Opening
0.045" (1.143 mm)Percent Open Area
50.70%Weight
0.348 lbs/sf (0.158 kgs/sf)
In comparison to mild steel, stainless steel tends to give off a brighter, more reflective finish that can lend itself to plenty of design applications. This is particularly useful in environments that have any sort of moist conditions as the material will not rust or corrode over time. Stainless steel mesh is particularly useful when it comes to drying racks or trays that are in contact with wet objects; any mild steel material would not work for this application as mild steel would corrode over time while stainless steel would not hence the price difference.Â
Due to the chromium content in stainless steel, this also makes the material more heat resistant than other types of steel. Some of the applications for stainless steel materials include:
-Concrete mesh
-Guarding
-Animal control
-Birdscreen
-Cabinetry
-Support screening
-Filtration
-Ventilation
For some of our more fine stainless steel patterns that have applications in filtering and sifting, metric measurements in microns are available (1 micron = 1 thousandth of a millimeter or 0.001 mm).
If you have any questions about our stainless steel market grade mesh or any other products, please call or email us.Â
