Stainless Steel
Product Code : SSWEA66063
Spec. Sheet
Centres or Mesh Count
6 x 6 MESH (4.2 mm x 4.2 mm) c to cWire Diameter
0.063" (1.600 mm)Clear Opening
0.104" (2.642 mm)Percent Open Area
38.90%Weight
1.646 lbs/sf (0.747 kgs/sf)
Product Code : SSWEA66035
Spec. Sheet
Centres or Mesh Count
6 x 6 MESH (4.2 mm x 4.2 mm) c to cWire Diameter
0.035" (0.889 mm)Clear Opening
0.132" (3.353 mm)Percent Open Area
62.70%Weight
0.486 lbs/sf (0.220 kgs/sf)
Product Code : SSWEA66047
Spec. Sheet
Centres or Mesh Count
6 x 6 MESH (4.2 mm x 4.2 mm) c to cWire Diameter
0.047" (1.194 mm)Clear Opening
0.120" (3.048 mm)Percent Open Area
51.80%Weight
0.891 lbs/sf (0.404 kgs/sf)
Product Code : SSWEA88017
Spec. Sheet
Centres or Mesh Count
8 x 8 MESH (3.2 mm x 3.2 mm) c to cWire Diameter
0.017" (0.432 mm)Clear Opening
0.108" (2.743 mm)Percent Open Area
74.60%Weight
0.150 lbs/sf (0.068 kgs/sf)
Product Code : SSWEA88028
Spec. Sheet
Centres or Mesh Count
8 x 8 MESH (3.2 mm x 3.2 mm) c to cWire Diameter
0.028" (0.711 mm)Clear Opening
0.097 (2.464 mm)Percent Open Area
60.20%Weight
0.415 lbs/sf (0.188 kgs/sf)
Product Code : SSWEA88035
Spec. Sheet
Centres or Mesh Count
8 x 8 MESH (3.2 mm x 3.2 mm) c to cWire Diameter
0.035" (0.889 mm)Clear Opening
0.090" (2.286 mm)Percent Open Area
51.80%Weight
0.658 lbs/sf (0.298 kgs/sf)
Product Code : SSWEA88047
Spec. Sheet
Centres or Mesh Count
8 x 8 MESH (3.2 mm x 3.2 mm) c to cWire Diameter
0.047" (1.194 mm)Clear Opening
0.078" (1.981 mm)Percent Open Area
38.90%Weight
1.221 lbs/sf (0.554 kgs/sf)
Product Code : SSWEA88063
Spec. Sheet
---Centres or Mesh Count
8 x 8 MESH (3.2 mm x 3.2 mm) c to cWire Diameter
0.063" (1.600 mm)Clear Opening
0.062" (1.575 mm)Percent Open Area
24.60%Weight
2.185 lbs/sf (0.991 kgs/sf)
Industrial wire mesh and wire cloth for use in filtration and sifting applications with various 304 and 316 options. 304 stainless steel is food grade stainless steel and is also commonly referred to as 18/10 stainless steel. 316 grade stainless steel is a highly corrosion resistant option that is suitable for marine environments, making it a slightly more expensive option.
